Panel-Mount DC Barrel Power Jack

Name: Panel-Mount DC Barrel Power Jack
Brand: SYY Tech

Panel-mount DC barrel power jack designed for extending DC power input to equipment panels, industrial enclosures, custom chassis and desktop power supply panels. Available in common sizes 5.5×2.1mm, 5.5×2.5mm and 3.5×1.3mm, with metal flange, locking nut and washer for secure panel installation. Suitable for power adapters, LED drivers, industrial control equipment, test instruments and custom device power ports.

Request a Quote

Enter the quantity you need and add to your quote list for pricing inquiries.

Quantity:

Categories: Panel Mount Interface Connectors

Description

This panel-mount DC barrel power jack provides a reliable DC power input solution for equipment panels, industrial enclosures, custom chassis, desktop power panels and test instrument front panels. It allows external DC power adapters, power supplies and battery packs to connect directly through the panel without opening the enclosure, making it widely used in industrial control equipment, LED displays, communication devices, test instruments, DIY electronic projects and custom power supply systems.

The connector features a standard barrel socket structure with an outer contact and an inner center pin, providing stable DC power transmission between the external power plug and internal device circuit. The metal flange, threaded body, locking nut and washer ensure firm installation on panels with standard cutouts, offering good vibration resistance and long-term connection stability in industrial environments.

This DC power jack is available in multiple common sizes to meet different application requirements. The 5.5×2.1mm and 5.5×2.5mm versions are widely used for medium-power DC input, while the 3.5×1.3mm version is suitable for smaller devices and low-power applications. Customers can select the appropriate size according to plug diameter, center pin diameter, current load and panel cutout size.

Constructed with metal housing and high-conductivity contacts, this panel-mount DC socket offers low contact resistance and good current-carrying performance. The insulator provides reliable separation between the outer contact and the inner center pin, helping to prevent short circuits and ensure safe power input. It is available in solder lug, PCB pin and wire harness versions, supporting different internal connection methods.

It is widely used for industrial equipment power input, LED driver panels, communication device power ports, test instrument power sockets, custom chassis front panels and desktop power distribution projects. The connector supports both permanent panel integration and prototype installation, making it suitable for equipment manufacturers, system integrators and electronic project builders.

Standard options include 5.5×2.1mm, 5.5×2.5mm and 3.5×1.3mm, with metal or black housing finish. Bulk orders can be customized with size, current rating, connection type, mounting thread length and private-label packaging.

Standard panel-mount DC barrel power jack for external DC power input
Available in 5.5×2.1mm, 5.5×2.5mm and 3.5×1.3mm common sizes
Metal flange, locking nut and washer for secure panel installation
High-conductivity contacts for low contact resistance and stable power transmission
Supports solder lug, PCB pin and wire harness internal connections
Suitable for industrial equipment, LED drivers, test instruments and custom chassis
Vibration-resistant mounting structure for industrial environments
Custom size, current rating, finish and packaging supported for bulk orders

Specifications

Item	Specification
Connector Type	DC Barrel Power Jack
Common Sizes	5.5×2.1mm / 5.5×2.5mm / 3.5×1.3mm
Mounting Style	Chassis / Panel Mount
Mounting Hardware	Metal Flange, Locking Nut, Washer
Contacts	Outer contact + inner center pin
Contact Material	High-conductivity copper alloy
Insulator	Black plastic insulator
Connection Method	Solder lug / PCB pin / wire harness optional
Panel Cutout	According to DC jack size
Current Rating	Standard 5A / 10A depending on model
Application	Industrial equipment power input, LED driver, communication device, test instrument, custom chassis
Custom Service	Size, current rating, connection type, thread length, logo marking, private packaging, OEM bulk orders

FAQ

Q: What is a panel-mount DC barrel power jack used for?

A: It is used to extend DC power input to equipment panels, industrial enclosures and custom chassis, allowing external DC power adapters and power supplies to connect without opening the enclosure.

Q: What sizes are available?

A: Common sizes include 5.5x2.1mm, 5.5x2.5mm and 3.5x1.3mm, which cover most DC power adapter and industrial device power port applications.

Q: How is it installed on the panel?

A: It is mounted through a standard panel cutout and secured with a metal flange, locking nut and washer, providing stable and vibration-resistant installation.

Q: What connection methods are available?

A: Common versions include solder lug, PCB pin and wire harness, depending on whether the internal connection is soldered wiring, PCB mounting or pre-assembled cable.

Q: Can it be used for LED driver panels?

A: Yes, it is frequently used for LED driver panels, industrial equipment power ports, communication devices and test instrument power sockets.

Q: Are custom versions available for bulk orders?

A: Yes, we support custom size, current rating, connection type, thread length, logo marking and private-label packaging for bulk OEM orders.
